Solid Granule Automatic Packaging Machine - Rotary Packaging Machine - 产品中心

MB8-200G/300G
Solid Granule Automatic Packaging Machine

Summary:

Bag-given packaging machine together with the multi heads weigher, with accurate measurement, fast packaging speed, stable operation and wide application range and other advantages, win the praise of customers, making the food industry packaging workshop into a mechanization

Main Performance and features

1. Candy, cornmeal, preserved fruit, chocolate, pan cake, cake, puffed food, etc.

2. Juice, tomato sauce, peanut sauce, chili sauce, washing liquid and detergent, etc.

3. Milk powder, coffee, spice and additive, etc.

4. Roasted seeds and nuts, dry fruit, leisure food.

Work Process

1. Feeding bag, 2. coding 3 opening bag, 4. filling vibration (1 time, 5. filling 2 time),6. Sealing( 1 time),7. Sealing(2 time) ,8 forming output

Main Technical Parameter

Model	MB8-200G	MB8-300G
Bags Specifications	W:70-200mm L:100-300mm	W:170-300mm W:200-500mm
Bag Type	Stand-up bags, handbags, zipper bags, 4-side sealing bags, 3-side sealing bags, paper bags, M type bags, compound bags, etc.
Filling range	20-5000g
Packing speed	35-55bags/min			15-45 bags/min
Weight	1500kg
Host power	4KW(no including vacuum pump)
Drive power	3-phase 5-wire system 380V 50HZ
Dimensions	3300×2800×3300mm		3800×2800×3300mm
	(without elevator,elevator height:4500mm)
Air consumption	≥0.4m³/min( compressed air provided by the user)

Sample

MB8-200G/300GSolid Granule Automatic Packaging Machine样品
